FEATURES

• Aluminum ALLOY CASING: Alloy casing has high heat - dissipation keeping motor and pump cool, light weight and efficient.
• Single-Stage Rotary Vane Vacuum Pump
• Direct drive motor allowing easy starting and is maintenance free.
• Direct coupling between the motor and pump results in quiet running and good performance.
• FORCE FED LUBRICATION Provides clean, filtered oil to all internal bearings and wearing surfaces regardless of the pump operation. Cleaner oil reduces ware and break downs.
• Good for: home and auto AC system evacuation, bell jar, desiccators, jewellery making/gluing jobs etc.
• Oil Capacity: 7 oz(220 ml)
• Come with a bottle of vacuum oil, just dump it in, you are ready to go!
• Oil drain valve positioned at bottom of oil reservoir.

SPECIFICATION:

• POWER SUPPLY :110 VOLT 60hz
• PUMPING RATE: 2.5 CFM
• LIMITED PRESSURE(Pa): 10
• POWER: 1/4 HP 1720RPM
• WEIGHT: 16 Lb
• 1/4" and 1/2" Fitting
  10-3/4" L x 4.5" W x 7"H (with out the handle) with handle 9" H
• Power cord: 5ft with 3-prong plug (UL North America standard: 15 A/125 VAC);
• power switch on the pump.
• 1x 5ft Charging Hose 2500PSI -500PSI (color may vary) 1/4" SAE fitting on both end
