40Amp 220V DC Inverter Plasma Cutter Welder Welding Machine w/Regulator Gauge

Categories: Welding Equipment
Item#: CUT40
Availability: In Stock

Plasma Cutter is a lightweight unit that features powerful inverter technology for smooth cutting. Handles almost any project you can throw at it, from mild steel to copper, brass, stainless and aluminum up to 3/8in. Cuts faster and more precise with a thinner kerf and less slag than cutting with oxy fuel. A smaller heat-affected zone also causes less warping. No gas pressure settings, flame tuning, metal preheating, or gas cylinders or refills to worry about, ever.

  • Features
    -Cutting capacity increased 1.8 times higher in cutting speed compare with flame cutter
    -Thick metal plate can be cut easily and quickly.
    -Suitable for cutting stainless steel, copper, iron and aluminium metal etc.
    -Simple operation, smooth cutting surface.
    -Hf untouched Arc-starting cutting (70,100,120)
    -Hf touched Arc-staring cutting (30,40,60).
Item WELD-CUT-40
Power voltage(V) 1~230
Rated input capacity(KVA) 4.8
No-load voltage(V) 230
Current range(A) 20-40
Rated output voltage(V) 96
Rated duty cycle(%) 60
Efficiency(%) 85
Insulation class F
Protection class IP21
Pressure Air Compressor (kg) 4.5
Measurement size and Weight 16" x 8" x11"  Aprox 22lbs
Max.cutting thickness(MM) 12
Burner Inter Diameter 1.0mm



Included: 220v 40A Plasma Cutting Machine 1.5M earth Clamp 4M cutting Torch Regulator Brush and Mask, 220v Plug Cable
