ARGON CO2 GAS MIG TIG FLOW METER WELDING WELD REGULATOR GAUGE WELDER CGA580 FITS

ARGON CO2 GAS MIG TIG FLOW METER WELDING WELD REGULATOR GAUGE WELDER CGA580 FITS

Categories: Welding Equipment
Item#: CGA580
Availability: In Stock
  • Argon Regulator Gauge Flow Meter
  • Easily adjust your gas flow rate with the built-in flow meter.  The flow meter measures gas flow in liters per minute (l/min) up to 25 l/min.
  • Output flow is adjustable from 0 to 30 LPM, and is indicated by a steel ball which moves up and down in the flow tube
  • Handles MIG and TIG welding both steel and aluminum
  • Fitting Type: CGA-580 fitting, compatible with all argon, helium, nitrogen, and argon/CO2 mixed gas tanks.
  • This item does not fit CO2 cylinders.  Please contact us or check out our eBay store for CO2 Flow meter
  • Outlet will fit both the female 9/16” x 18 nut and the male 5/8" x 18 fitting BRASS FITTING
  • Comes with a standard 1/3" " barbed fitting.
  • If you do have a Miller, Lincoln, or Hobart welder, the gas hose from your machine should screw right in, as they should use the 5/8" x 18 male nut
  • this flow meter does not use a diaphragm, so it is more reliable than the flow-gauge type regulators
  • Specially designed TIG or MIG Welding
  • 0-30 LPM EQUAL TO 0-63.5 CFH
  • Fit Standard CGA 580 argon tank
  • Hose not included
