230V ETL Flux MIG WELDER 156 GAS WELDING MACHINE AUTO FEEDING WELD w/Wire

Categories: Welding Equipment
Item#: mig156
Availability: In Stock
  • High quality dual mig welder  can be use with or without gas ! Complete ready to use kit comes with torch, tip, grounding cord and other accessories.

  • Scroll down and check out the description and detail pictures.

    • Perfect for mild steel, stainless steel, and aluminum welding.

    • Input Voltage: 230V/60Hz AC, SINGLE PHASE

    • ITEM.MIG156

      •Reversible polarity for Gas MIG or Flux Wire welding
      •230V/50Hz, ETL approved
      •No Load Voltage: 36V

    • Max Input Capacity: 4.8kVA

    • Max no-load Voltage: 36 VDC
      •Adjustment Positions: 4 Steps
      •Range of current 30-120amp
      •Duty Cycle: 20 %@105A ; 39%@75A ; 88%@50A ; 100%30A
      •Insulation Class: H
      •Dia. Usable Wire: .023",.030".035" for steel of stainless stell wire
                                     .030",.035" for aluminum wire
                                    .030" for flux wire
      Includes: Welding torch, tip, grounding cord with clamp
                       Brush/hammer, Face shield, Flux welding wire .030", wrench

    • 220v Plug is not included
    • AProx 16" x 9.5" x 12.5" (h)
